Marantz SACD 30n CD Players
SACD 30N CD PLAYERS
SACD 30N CD PLAYERS
SACD 30n was designed for the experienced audiophile who appreciates flexibility in format and expects the most realistic sound.
Hundreds of hours of careful Sound Master tuning ensure the exquisite detail and musicality Marantz has always delivered.
Technology
THE COMPLETE DIGITAL MUSIC PLAYER
SACD 30n is built to meet all the requirements of the modern audiophile who wants to combine a large digital music collection with the leading online music services.
THE MOST MUSICAL,ACCURATE,DETAILED SOUND
SACD 30n is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM.
SOUND MASTER TUNED
The Marantz Sound Master meticulously tuned SACD 30n for amazing performance with careful parts selection to create the Most Musical Sound in your home.
LEGACY SYSTEM CONNECTIVITY
SACD 30n integrates the Marantz Musical Mastering digital-to-analog converter.
INFORMATION
BRAND
Marantz
WEIGHT
13.5 kg
COLLECTION
REMOTE CONTROL
RC002PMND
MAXIMUM DIMENSIONS
- Width : 443 mm
- Depth : 424 mm
- Height : 130 mm
METAL FRONT PANEL
Yes
POWER CONSUMPTION IN W
48
STANDBY CONSUMPTION IN W
0.4
DETACHABLE POWER CABLE
Yes
AUTO POWER OFF
Yes
SIGNAL TO NOISE RATIO
104 dB
PLAYBACK
- Repeat : Yes
- Random Play : Yes
- Program Play (CD / SA-CD) : 25/No
COLORS
- Black
- Silver Gold
FREQUENCY RESPONSE
2 Hz - 20 kHz
PRODUCTION
Made in United States
DYNAMIC RANGE
109 dB
TOTAL HARMONIC DISTORTION
0.00002
MAXIMUM DIMENSIONS
- Width : 534 mm
- Depth : 522 mm
- Height : 255 mm
OTHERS
- Display: Dimmer / Off : Yes / Yes
- Marantz Musical Mastering : Yes
- Marantz Musical Mastering Conversion : Yes
- Marantz Musical Mastering Stream : Yes
- Selectable filter: CD / SA-CD / DAC-Mode : Yes/ No / Yes(PCM only)
- Separated rectifier circuit for analogue and digital circuitry : Yes
CHANNEL SEPARATION
No
CARTON WEIGHT
16.2 kg
NETWORK
- App control AMP/CD via Network Player : Yes
- Bluetooth on / off mode : Yes
- DSD Audio Streaming : up to DSD5.6
- Gapless Playback : Yes (FLAC, WAV, DSD)
- Lossy formats MP3 / WMA / AAC : Yes / Yes / Yes
- Remote APP: iDevice / Android : Yes / Yes
- Wi-Fi on / off mode : Yes
- Wi-Fi / Wired LAN : 2.4GHz, 5GHz / Yes
- Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 : Yes / Yes / Yes / Yes
DETAIL
-Crafted in Shirakawa, Japan -Exclusive HDAM -HEOS Built-in -SACD, CD & DVD Support -DSD Support -Marantz Musical Mastering DAC
SPECIFICATIONS
- Channel Separation (SA) : No
- D/A Conversion : MMM
- DAC IC : MMM
- Digital Filter : MMM
- Dynamic Range : 98 dB
- Output Buffer : HDAM SA3
- Total Harmonic Distortion (SA) : 0.0008%
- Frequency Response (Cust.) : 2 Hz - 20 kHz
- Headphone amp : HDAM SA3
- Low Pass Filter stage : HDAM
- Mechanism : SACDMNo3L
- Noise Shaper : MMM
- Signal to Noise Ratio (SA) : 112dB
INPUTS/OUTPUTS
- D-Bus : Yes
- Balanced Out : No
- Analogue Out (Cinch) : 1
- Digital Coaxial In / Out : 2 / 1
- Digital Optical In / Out : 1 / 1
- Ethernet port : Yes
- Flasher Input : Yes
- Gold Plated Cinch : Yes
- Headphone Out : Yes
- Headphone Volume Control : Yes
- IP control : Yes
- RS232 : Yes
- Sample Rate digital In : 192 kHz / 24-bit
- USB Audio (front) : Yes (rear)
- USB type B input for PC (rear) Sample Rate USB type B In : Yes up to DSD11.2
- Variable Out (Cinch) : 1
KEY TECHNOLOGIES
KEY TECHNOLOGIES
KEY FEATURES
- Air Play 2 : Yes
- Internet radio : tunein
- Jitter reducer : Yes
- Roon Tested : Yes
- Copper Plated Chassis : No
- Customised Components : Yes
- Symmetric circuit layout : Yes
- USB input for memory stick : Yes
- Network Audio Streaming : Yes
- Power Transformer: Toroidal / El : Yes / No
- USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 : No
- DAC operation mode: USB B type / Coax / Optical : No / No / No
- CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC : Yes / Yes / No / Yes / Yes / No
- HDAM version : HDAM+HDAM SA2
- Bit-perfect transmission : No
- HEOS Multiroom and Streaming : Yes
- High Grade Audio Components : Yes
- Digital out off / Audio EX Mode : Yes / No
- Asynchronous mode rear USB : No
- Power Transformer: Toroidal / El : No / Yes
- Data Disc Compatibility: DSD / WAV / ALAC : No / No / No
- CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data : No / No / Yes / Yes / Yes
- Spotify Connect* / Tidal* / Deezer* / others * : Yes / Yes / Yes / Yes
- Amazon Prime Music* / Pandora* : Yes / No
- Voice Control - Microphone built-in : No
- Signal isolator for DAC Mode operation : No
- Voice Control - Works with Amazon Alexa : Yes
- Voice Control - Google Assist / Apple Siri : Yes / Yes
- Headphone: Standard / Buffer / Current feedback : No / Yes (HDAM-SA2) / No
