Wharfedale Vista 200 Speaker System
VISTA 200 SPEAKER SYSTEM
VISTA 200 SPEAKER SYSTEM
The Vista 200 delivers a significant sonic upgrade despite its low-profile design and thoroughly modest price tag. Just 90cm in length and only 6.2cm high, its long and slender form sits unobtrusively beneath the screen without spoiling even the most stylish TV aesthetic.
INFORMATION
BRAND
Wharfedale
PRODUCT TYPE
Speaker
POWER SUPPLY
AC 100-240V ~ 50/60Hz
POWER CONSUMPTION
80 W / <0.5 W(Standby)
GENERAL DESCRIPTION
Soundbar system
MODEL
Vista 200
OUTPUT POWER
30W x 2
FREQUENCY RESPONSE
40Hz - 20KHz
AUDIO INPUT SENSITIVITY (AUX)
500mV
DIMENSIONS
- Length : 900
- Height : 62
- Width : 92 mm
HIGH-QUALITY DYNAMIC DRIVER ASSEMBLIES
Placed on a TV stand or mounted on a wall, its smart, gloss-black finish always looks the part. Nestling behind the metal speaker grille is a pair of high-quality dynamic driver assemblies, positioned at either end of the soundbar’s length to ensure spacious stereo sound and augmented by two reflex ports to aid bass response.
BLUETOOTH VERSION
V 4.2
FREQUENCY BANDS
2402MHz ~ 2480MHz
WARRANTY
3 Year Warranty
SPEAKERS LMPEDANCE
8Ω x 2
MAXIMUM POWER TRANSMITTED
<5 dbm
PLACEMENT AND INSTALLATION
- A If your TV is placed on a table, you can place the unit on the table directly in front of the TV stand, centered with the TV screen.
- B If your TV is attached to a wall, you can mount the unit on the wall directly below the TV screen.
DETAIL
These drivers are powered by 2x30W stereo amplification, producing a sound that is crisply detailed yet tonally rich – a powerful, highly intelligible delivery that ensures voices are clear, sound effects are impactful, and music is full-bodied and engaging.
In addition, three equaliser settings labelled ‘Movie’, ‘Music’ and ‘News’ provide a degree of sonic tailoring to suit whatever the user is watching or listening to. Connecting the Vista 200 to a TV is simple. There are three digital inputs: HDMI (ARC), optical and coaxial. There is also a 3.5mm analogue input, which means you can connect a TV (or an audio device) via an RCA or headphone output.
The Vista 200 also has Bluetooth built-in, enabling users to pair devices like smartphones, tablets and laptops and benefit from the soundbar’s rich, room-filling sound when streaming music or watching video content.
USER INSTRUCTIONS
PREPARE THE REMOTE CONTROL
The provided Remote Control allows the unit to be operated from a distance.
- Even if the Remote Control is operated within the effective range 6m, remote control operation may be impossible if there are any obstacles between the unit and the remote control.
- If the Remote Control is operated near other products which generate infrared rays, or if other remote control devices using infra-red rays are used near the unit, it may operate incorrectly. Conversely, the other products may operate incorrectly.
REPLACE THE REMOTE CONTROL BATTERY
The remote control requires a CR2025. 3V Lithium battery.
- Push the tab on the side of the battery tray towards the tray.
- Now slide the battery tray out of the remote control.
- Remove the old battery. Place a new CR2025 battery into the battery tray with the correct polarity (+/-) as indicated.
- Slide the battery tray back into the slot in the remote control.
PRECAUTIONS CONCERNING BATTERIES
- Never throw them in fire or water.
- Do not heat or disassemble batteries.
- Do not use any batteries other than those specified.
- Do not carry or store batteries with other metallic objects.
- Doing so could cause batteries to short circuit, leak or explode.
- Never recharge a battery unless it is confirmed to be a rechargeable type.
- When the Remote Control is not to be used for a long time (more than a month), remove the battery from the Remote Control to prevent it from leaking.
- If the batteries leak, wipe away the leakage inside the battery compartment and replace the batteries with new ones.
