Kratki Wood Burning Cast Iron Stove Kratki K7 Ø 130 5 Kw
WOOD BURNING CAST IRON STOVE KRATKI K7 Ø 130 5 KW
WOOD BURNING CAST IRON STOVE KRATKI K7 Ø 130 5 KW
SKU : KOZA/K7
INFORMATION
CERTIFICATIONS / COMPLIANCE
Certificates : Ecodesign
BRAND
Kratki
PRODUCT TYPE
Stove
EAN
5901350039670
EQUIPMENT
Ashpan
NUMBER OF PIECES IN A PACKAGE.
4
ENERGY CLASS
A
COLOR
Black
EEI
91
BASE MATERIAL
Cast iron
NOMINAL POWER (KW)
5 kw
HEATING POWER RANGE (KW)
3.0 - 8.0 kw
FRONT
Cast iron front with ceramic glass
FUEL TYPE
Seasoned deciduous wood (humidity ≤20%)
TECHNICAL DRAWING
PHYSICAL PARAMETERS
- Width : 53.6 cm
- Depth : 41.3 cm
- Height : 55.7 cm
WEIGHT
75 kg
FLUE GAS TEMPERATURE
287 oC
THERMAL EFFICIENCY (%)
70 %
OPTIMAL LOG LENGTH
300 mm
MAX BILLET LENGTH
35 cm
ADDITIONAL CLOSING
No
DIAMETER OF THE FLUE GAS OUTLET
150
SEASONAL ENERGY EFFICIENCY
60 %
DOOR OPENING
Left
OPTIONAL EQUIPMENT
None
CO EMISSION (MG/M3)
1761 mg/m3
POLLEN EMISSION (MG/M3)
15 mg/m3
HEAT OUTPUT FOR SPACE HEATING
5 kW
CO EMISSION (AT 13% O2) ≤ GIVEN IN %
0.141
NOX EMISSION (MG/M3)
95 mg/m3
OGC EMISSION (MG/M3)
109 mg/m3
MAXIMUM USE OF ENERGY
- Combustion of fuel particles thanks to the deflector, which extends the exhaust gas path.
- Maximum use of heat and trouble-free operation thanks to the walls of the device made of high-quality cast iron with a thickness of 8 mm.
FLUE GAS MASS FLOW (G/S)
8.1
ENVIRONMENT
Indoor
SAFETY AT THE HIGHEST LEVEL
- The Classic front of the stove is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C.
- Decorative fence helps to maintain tidiness and protects against falling out of wood.
CONVENIENT TO USE
- The cold handle system allows for disassembly when the stove is in use.
- Reduced soot deposition through a system of pure glass (air curtain).
- Ash drawer/ashtray, where burnt wood remains are gathered and grated for easy ash removal.
- The possibility of different assembly, thanks to the adjustable flue gas outlet from the back or top of the stove.
