Kratki Wood Burning Steel Stove Kratki K5 Ø 150 7 Kw
KRATKI WOOD BURNING STEEL STOVE KRATKI K5 Ø 150 7 KW
KRATKI WOOD BURNING STEEL STOVE KRATKI K5 Ø 150 7 KW
INFORMATION
BRAND
Kratki
PRODUCT TYPE
Stove
CERTIFICATIONS / COMPLIANCE
Certificates : Ecodesign, BImSchV 2
SKU
- White : KOZA/K5/S/W
- Black : KOZA/K5/S/W/BLACK
EAN
5901350090183
FRONT
Steel front with ceramic glass
BASE MATERIAL
Steel
ENERGY CLASS
A
FUEL TYPE
Seasoned deciduous wood (humidity ≤20%)
NUMBER OF PIECES IN A PACKAGE
2
EQUIPMENT
- Ashpan
- Firewood niche
- Adjustable feet M10
- Combustion chamber lining
HEAT OUTPUT FOR SPACE HEATING (KW)
7
EEI
100
SEASONAL ENERGY EFFICIENCY
66 %
CO EMISSION (AT 13% O2) ≤ GIVEN IN %
0.088 %
TECHNICAL DRAWING
CO EMISSION (MG/M3)
1106 mg/m3
NOX EMISSION (MG/M3)
114 mg/m3
OGC EMISSION (MG/M3)
69 mg/m3
FLUE GAS MASS FLOW (G/S)
7.8 g/s
WEIGHT
125 kg
SAFETY AT THE HIGHEST LEVEL
- Decorative fence helps to maintain tidiness and protects against falling out of wood.
- The Classic front of the stove is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C.
PHYSICAL PARAMETERS
- Width : 46.2 cm
- Depth : 39.9 cm
- Height : 92.6 cm
CONVENIENT TO USE
- The cold handle system allows for disassembly when the stove is in use.
- Reduced soot deposition through a system of pure glass (air curtain).
- Ash drawer/ashtray, where burnt wood remains are gathered and grated for easy ash removal.
- The possibility of different assembly, thanks to the adjustable flue gas outlet from the back or top of the stove.
NOMINAL POWER
7 kW
HEATING POWER RANGE
5.5 - 9.0 kW
DIAMETER OF THE FLUE GAS OUTLET
150
MAX BILLET LENGTH
30 mm
FLUE GAS TEMPERATURE
175 °C
COLOR LINING
- White
- Black Thermotec
THERMAL EFFICIENCY (%)
76 %
ADDITIONAL CLOSING
No
DOOR OPENING
Left
OPTIMAL LOG LENGTH
200 mm
MAXIMUM USE OF ENERGY
- Combustion of fuel particles thanks to the deflector, which extends the exhaust gas path.
- Maximum use of heat and trouble-free operation thanks to the walls of the device made of high-quality steel with a thickness of 8 mm.
