BULLERJAN B³ CERAMIC MAX STOVE
BULLERJAN B³ CERAMIC MAX STOVE
As of now, the B³ can also be selected as an all-ceramic version without the distinctive cast elements. Of course, the design possibilities of the B³ Ceramic MAX are also almost unlimited.
A stylish stove which, in terms of its visual design, is completely in line with your taste and your furnishings. Even the interior lining of the stove can be optionally lined in creamy white or black.
The B³ ceramic MAX - from now on the B³ can also be chosen as an all-ceramic version without the distinctive cast elements. Of course, the design possibilities of the B³ ceramic MAX are also almost unlimited. A stylish stove that is completely in line with your taste and your interior design in terms of its visual design.
Even the inner lining of the stove can be lined in either cream white or black. The B³ ceramic is a compact and modern interpreted tiled stove with excellent fire and heating properties. Its harmonious proportions and the clear, stylish design language make the B³ a timelessly beautiful furnishing object.
INFORMATION
BRAND
Bullerjan
PRODUCT TYPE
Stove
EFFICIENCY
- 84 %
- 86 %
- 88 %
ENERGY EFFICIENCY INDEX (EEI)
- 112
- 115
- 118
DETAIL
Due to its metered heat output, its power range from 3.9 to 6 kW and its small space requirement, the B³ is very suitable for small or particularly well insulated rooms. It also convinces as an additional heater and stylish design statement in larger living spaces. Of course, we also offer many different ceramic glazes for this stove. With the appropriate lead time, we can often even produce individual desired colours.
EXHAUST GAS NOZZLE
15 cm
AIR SUPPLY NOZZLE
10 cm
FLUE GAS CONNECTION
Independent of room air (RLU) according to DIBt
WITH DRAFTBOX
Higher efficiency and further emission reduction thanks to the draft box.
DISTANCE FROM COMBUSTIBLE MATERIALS (SIDES / BACK / FRONT)
- Sides : 15 cm
- Back : 30 cm
- Front : 80 cm
CATALYTIC CONVERTER
Mit ChimCat-Katalysator (3,9 kW und 6,0 kW) Ohne Katalysator (5 kW)
HEIGHT CENTRE AIR SUPPLY NOZZLE
Approx. 55.2 cm
TESTED NOMINAL HEAT OUTPUT (NHO)
- 3.9 kW
- 6.0 kW
- 5.0 kW
EXHAUST GAS MASS FLOW RATE
- 4.66 g/s
- 5.13 g/s
- 4.11 g/s
WEIGHT
237 kg
PRODUCTION
Made in Germany
HEIGHT CENTRE EXHAUST GAS NOZZLE
Approx. 118 .5 cm
AVERAGE FLUE GAS TEMPERATURE
- 252 °C
- 277 °C
- 223 °C
MAIN PRODUCT FEATURES
- Elegant timeless design
- Flue connection either at the rear or on the top
- Compact radiation stove with significant storage capacity
- Nominal heat output of 5 kW without catalytic converter and 9 to 6 kW with catalytic converter
- Highly economical through extremely high efficiency factors of up to 88 percent
- Fireclay filled storage tiles hand made in Germany
- Individual design options through wide choice of ceramic glazes
CO CONTENT (13% O2)
- 419.9 mg/m3
- 260.0 mg/m3
- 1172.9 mg /m3
DELIVERY PRESSURE
12 Pa
FIRE BOX LINING
Black & Beige
AVERAGE CO2 CONTENT
- 7.38 %
- 9.47 %
- 10.47 %
FUNCTION AND QUALITY – MADE IN GERMANY
- Extremely solid combustion chamber of 4 mm thick, edged steel.
- Potential wear parts, can be replaced even after years, if necessary
- Simple control of the fire through precisely coordinated air supply regulation
- Warranty extension (total 5 years) to the stove body on registering the product
- Comprehensive service offering by the Bullerjan specialist dealers or Bullerjan customer service
- High effiency factor of 82 %
- Firebox lined with high-quality coloured vermiculite
- Self-closing and -locking door with large viewing window
- External air supply connection (if required) behind or below
DUST & NOX (13% O2)
- 29.9 mg/m3
- 28.9 mg/m3
- 36.9 mg/m3
NOMINAL HEAT OUTPUT
- 6 kW
- 8 kW
- 10 kW
ENERGY EFFICIENCY CLASS
A+
DEPTH OF COMBUSTION CHAMBER
25.5 cm
