Kratki Wood Burning Cast Iron Stove Kratki K5 Ø 130 7 Kw
WOOD BURNING CAST IRON STOVE KRATKI K5 Ø 130 7 KW
WOOD BURNING CAST IRON STOVE KRATKI K5 Ø 130 7 KW
Maximum Use Of Energy
Combustion of fuel particles thanks to the deflector, which extends the exhaust gas path.
Maximum use of heat and trouble-free operation thanks to the walls of the device made of high-quality cast iron with a thickness of 8 mm.
INFORMATION
SAFETY AT THE HIGHEST LEVEL
- Decorative fence helps to maintain tidiness and protects against falling out of wood.
- The Classic front of the stove is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C.
BRAND
Kratki
PRODUCT TYPE
Stove
POWER
- Nominal power : 7 Kw
- Heating power range : 5.5 - 9.0 Kw
EAN
5901350024607
SKU
KOZA/K5
ENERGY CLASS
A
THERMAL EFFICIENCY (%)
76 %
FLUE GAS TEMPERATURE
250 °C
CERTIFICATIONS / COMPLIANCE
Certificates : Ecodesign, BImSchV 2
OPTIMAL LOG LENGTH
200 mm
MAX BILLET LENGTH
30 mm
COLOR
Black
ADDITIONAL CLOSING
No
WEIGHT
118 kg
PHYSICAL PARAMETERS
- Width : 45.2 cm
- Depth : 40.6 cm
- Height : 62.8cm
CONVENIENT TO USE
- The cold handle system allows for disassembly when the stove is in use.
- Reduced soot deposition through a system of pure glass (air curtain).
- Ash drawer/ashtray, where burnt wood remains are gathered and grated for easy ash removal.
- The possibility of different assembly, thanks to the adjustable flue gas outlet from the back or top of the stove
FRONT
Cast iron front with ceramic glass
BASE MATERIAL
- Steel
- Cast iron
DIAMETER OF THE FLUE GAS OUTLET
- 150
- 130
EEI
100
FLUE GAS MASS FLOW (G/S)
7.8 g/s
SEASONAL ENERGY EFFICIENCY
66 %
CO EMISSION (MG/M3)
1106 mg/m3
POLLEN EMISSION (MG/M3)
40 mg/m3
HEAT OUTPUT FOR SPACE HEATING (KW)
7 Kw
NOX EMISSION (MG/M3)
114 mg/m3
OGC EMISSION (MG/M3)
69 mg/m3
WARRANTY
All the products available at www.kratki.com are brand new, free from any physical or legal defects. The Producer grants a 5-year warranty from the moment of purchase of a stove for its reliable operation. Grate and sealing for the stove are covered with a 1-year warranty from the moment of the purchase of the stove.
The warranty shall not cover heat-resistant ceramics. The application of the stove, the method of joining with the chimney as well as the terms and conditions of use must correspond with the manual.
OPTIONAL EQUIPMENT
None
DOOR OPENING
Left
NUMBER OF PIECES IN A PACKAGE
2
EQUIPMENT
- Ashpan
- Combustion chamber lining
CO EMISSION (AT 13% O2) ≤ GIVEN IN %
0.088 %
FUEL TYPE
Seasoned deciduous wood (humidity ≤20%)
TECHNICAL DRAWING
