Kratki Tiled Wood Burning Steel Stove Kratki Wk440 Ø 130 5,5 Kw Cream Til
TILED WOOD BURNING STEEL STOVE KRATKI WK440 Ø 130 5,5 KW CREAM TIL
TILED WOOD BURNING STEEL STOVE KRATKI WK440 Ø 130 5,5 KW CREAM TIL
Design reffering to retro style - glossy tile panels.
The casing from tile panels effects for prolonged heat rejection, which provides additional source of heating after extinction.
INFORMATION
SAFETY AT THE HIGHEST LEVEL
- Perfect tightness thanks to the solid welds made in a noble gas shielding.
- All steel elements are laser cut and bent on CNC bending machines.
- Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
BRAND
Kratki
PRODUCT TYPE
Stove
CERTIFICATIONS / COMPLIANCE
Certificates : Ecodesign, BImSchV 2
SKU
WK/440/KAFEL/K
EAN
5901350059654
THERMAL EFFICIENCY
80 %
FLUE GAS TEMPERATURE
279 °C
FUEL TYPE
Seasoned deciduous wood (humidity ≤20%)
PHYSICAL PARAMETERS
- Width : 75 cm
- Depth : 37.7 cm
- Height : 74.8 cm
WEIGHT
130 kg
MAX BILLET LENGTH
30 cm
BASE MATERIAL
- Steel
- Tile
ENERGY CLASS
A
ADDITIONAL CLOSING
No
POWER
- Nominal power : 5.5 kW
- Heating power range : .0 - 9.3 kW
EEI
106
DOOR OPENING
Left
DIAMETER OF THE FLUE GAS OUTLET
130
MAXIMUM USE OF ENERGY
- Manual control over the combustion process carried out by ash tray regulator.
- The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
- Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
EQUIPMENT
Ashpan, Combus
tion chamber lining
CO EMISSION (AT 13% O2) ≤ GIVEN IN %
0.099 %
TECHNICAL DRAWING
STYLE & DESIGN
Stoves with tile panels produced by Kratki company are classified as solid-fuel boiler with manual loading of fuel and lockable door. They are used as additional source of heating in interiors where they are installed.
SEASONAL ENERGY EFFICIENCY
70 %
CO EMISSION (MG/M3)
1237 mg/m3
HEAT OUTPUT FOR SPACE HEATING (KW)
5.5 Kw
POLLEN EMISSION (MG/M3)
31 mg/m3
NOX EMISSION (MG/M3)
110 mg/m3
CONVENIENT TO USE
Reduced soot deposition through a system of pure glass (air curtain).
FLUE GAS MASS FLOW (G/S)
4.7 g/s
OGC EMISSION (MG/M3)
85 mg/m3
